AIP18-30H
Talk to our Experts
Production-Scale HIP System
The AIP18-30H is a production hot isostatic press designed for organisations moving from pilot-scale processing to reliable industrial production.
Featuring AIP’s advanced furnace design and computer-controlled operation, the system supports consistent high-pressure and high-temperature processing while helping manufacturers improve productivity and return on investment.
With a furnace-dependent working diameter of 12–13 inches, a working length of 16–30 inches, and a pressure capability of 30,000 psi / 207 MPa, the AIP18-30H provides a flexible platform for production HIP requirements.
Built for Production HIP Requirements
The AIP18-30H is designed for users who require more processing capacity than pilot-scale equipment while maintaining straightforward operation and dependable performance.
Its combination of a larger working zone, multiple furnace configurations and advanced computer control makes it suitable for developing repeatable production processes.
The system can be supplied with either a threaded pressure vessel or a plate-frame pressure vessel, depending on the selected configuration and project requirements.
Key Product Advantages
30,000 psi Pressure Capability
The AIP18-30H provides a typical pressure capability of 30,000 psi / 207 MPa for production hot isostatic pressing.
Flexible Working-Zone Dimensions
Depending on the selected furnace configuration, the system offers a working diameter of 12–13 inches and a working length ranging from 16–30 inches.
Multiple Furnace Options
The system supports iron, molybdenum and carbon furnace configurations for different temperature requirements.
High-Temperature Processing
The carbon furnace configuration provides a source-listed operating temperature of up to 2000°C.
Advanced Computer Control
AIP’s computer-control system supports controlled operation and repeatable production cycles.
Reliable Production Performance
The system is engineered for dependable industrial operation and straightforward day-to-day use.
Flexible Pressure-Vessel Design
Customers can evaluate threaded and plate-frame pressure-vessel configurations according to their production requirements.
Custom System Dimensions
AIP can supply customised working-zone dimensions to meet specialised processing needs.
Furnace Options
| Furnace Type | Source-Listed Temperature |
|---|---|
| Iron Furnace | 1200°C |
| Molybdenum Furnace | 1450°C |
| Carbon Furnace | 2000°C |
AIP Production HIP System Comparison
| Model | Furnace Temperatures and Types | Working Diameter | Working Length | Pressure | Pressure Vessel |
|---|---|---|---|---|---|
| AIP18-30H | 1200°C Fe, 1450°C Mo, 2000°C Carbon | 12–13 in | 16–30 in | 30,000 psi / 207 MPa | Threaded or Plate Frame |
| AIP24-30H | 1200°C Fe, 1400°C Mo, 2000°C Carbon | 18–21 in | 24–60 in | 30,000 psi / 207 MPa | Threaded or Plate Frame |
| AIP28-30H | 1200°C Fe, 1400°C Mo, 2000°C Carbon | 20–22 in | 30–72 in | 30,000 psi / 207 MPa | Threaded or Plate Frame |
| AIP32-30H | 1200°C Fe, 1400°C Mo, 2000°C Carbon | 22–26 in | 40–80 in | 30,000 psi / 207 MPa | Threaded or Plate Frame |
| AIP36-22H | 1200°C Fe, 1350°C Mo, 1850°C Carbon | 26–31 in | 48–100 in | 22,000 psi / 150 MPa | Threaded or Plate Frame |
| AIP48-15H | 1175°C Fe, 1350°C Mo, 1800°C Carbon | 38–42 in | 60–120 in | 15,000 psi / 103 MPa | Threaded or Plate Frame |
| AIP60-15H | 1150°C Fe, 1350°C Mo, 1800°C Carbon | 50–52 in | 72–120 in | 15,000 psi / 103 MPa | Threaded or Plate Frame |
Why Choose the AIP18-30H?
The AIP18-30H is suitable for organisations that need a flexible production HIP system without moving directly to the largest available equipment.
It provides:
- Production-scale processing capacity
- 30,000 psi / 207 MPa pressure capability
- Up to 2000°C source-listed furnace temperature
- Multiple furnace configurations
- Threaded or plate-frame vessel options
- Advanced computer control
- Reliable and simple operation
- Custom dimension availability
FAQs
The AIP18-30H is available with iron, molybdenum and carbon furnace configurations.
